LEYBONOL Vacuum Oil LVO100

产品简介:

Model:LVOLVOLVO-100 5L 20L Brand:LEYBOLD LEYBONOL Vacuum Pump Oil LVO100 Mineral oil is a product distilled and refined from crude oil. These do not include precisely defined compounds, but rather a complex mixture. The pre-treatment of the mineral oil and the way it is composed are decisive factors in determining its suitability for the application. Based on the distribution of hydrocarbons and the dominant position with certain characteristics, mineral oils are grouped according to paraffin, cycloalkyl, and aromatic groups. For the purpose of achieving extremely low ultimate pressure, it is necessary to choose a core fraction based on mineral oil. The thermal stability and chemical resistance of mineral oils have been found to be sufficient in most applications, providing a high compatibility with elastomers and resistance to hydrolysis. Oil type Description, Product Example ISO VG Viscosity.

1The window where oil is filled must be clean, and strictly prohibited to be exposed to sunlight or stored outdoors. It should be stored in a dark, dry, and ventilated environment to prevent the mixing of water and dust.

2When taking or filling oil, the light rain around the barrel cover must be completely removed to prevent debris from mixing into the oil and causing pump wear.

3 Vacuum pump oils of different grades and varieties cannot be mixed, and new and used oils cannot be mixed.

4 Strictly avoid mixing vacuum oil with other lubricating oils, and do not mix light oil products, otherwise it will affect the vacuum pumping.

5 Solvents, water vapor, and corrosive gases pumping should be avoided. The oil must be checked and replaced frequently when in use.

6 When changing the oil, the used oil in the pump should be drained. After filling in new oil, slowly rotate the pump shaft, clean the pump chamber to drain the remaining oil, repeat the cleaning several times, and then replace with new oil.

7During pump overhaul, all components of the pump must be cleaned with solvents or cleaning agents and dried.

8Refueling equipment must be specialized and should not be a container or pump that has been used to hold other oils or solvents.

9 When mineral oil is exchanged with ester oil or other synthetic oils, the pump should be disassembled and thoroughly cleaned. All components must be immersed in the oil to prevent contamination.

10If chemical gases and solvents are inhaled and affect the vacuum pumping, it must be cleaned and replaced.

11Oil change deadline: a. When the vacuum pumping drops and cannot meet the needs; b. When the color of the pump oil becomes darker and brown, the oil should be changed.
